Rear door right gas spring body bracket
OE / Material Codes
13732964-00SC2EM-6309114Technical Specifications
- Vehicle Model
- BYD Atto 3
- Steering Configuration
- Universal (Left & Right-Hand Drive)
- Category
- Doors & Tailgates
Shipping & Returns
Ships worldwide from Shanghai, China via air or sea freight. Standard delivery 5–30 business days, express 2–10 business days. Shipping cost is calculated at checkout.
7-day return window for unused items in original packaging. Contact us before returning any item.
Compatible Vehicles — Rear door right gas spring body bracket
Rear door right gas spring body bracket Workshop Guide — BYD Atto 3
Right Rear Door Lock Body Assembly - Removal and Installation
Removal
- Remove the right rear door rear movable guide rail and mud tank assembly. See Right Rear Door Rear Movable Guide Rail and Mud Tank Assembly - Removal and Installation
- Detach one fixing clip, and detach the right rear door lock outward-opening lever from the right rear door lock body assembly.
- Remove 3 fixing bolts of the right rear door lock body assembly.
- Disconnect one connector, and take out the right rear door lock body assembly.
Caution To take out the rear door lock body assembly, the rubber plug connecting the rear door lock body assembly and the door shall be detached first.
Installation
- Follow the removal steps in reverse order to install.
Caution After the installation, check the functionality of the rear door lock body assembly.
Tailgate Left Gas Spring Door Bracket - Removal and Installation
Removal
- Open the tailgate.
- Pry up the pin with a minisize flat-head screwdriver, and detach from the tailgate left gas spring door bracket.
- Remove 2 fixing bolts, and take out the tailgate left air spring door bracket.
Caution When detaching the tailgate left air spring body, the help of another technician is required to support the tailgate assembly. When prying up the pin with a minisize slot type screwdriver, do not pry up the pin completely from the ball cage.
Installation
- The installation steps are opposite to the removal steps.
Left Rear Door Lock Body Assembly - Removal and Installation
Removal
- Remove the left rear door rear movable guide rail and mud tank assembly. See Left Rear Door Rear Movable Guide Rail and Mud Tank Assembly - Removal and Installation
- Remove 3 fixing bolts of the left rear door lock body assembly.
- Detach one fixing clip, and detach the left rear door lock outward-opening lever from the left rear door lock body assembly.
- Disconnect one connector, and take out the left rear door lock body assembly.
Caution To take out the rear door lock body assembly, the rubber plug connecting the rear door lock body assembly and the door shall be detached first.
Installation
- Follow the removal steps in reverse order to install.
Caution After the installation, check the functionality of the rear door lock body assembly.
