OEM
BYD Atto 3
AC/DC charging port cover assembly I
OE / Material Codes
13508617-00SC2E-8403840A$36USD
In StockNeed bulk or wholesale pricing?
Technical Specifications
- Vehicle Model
- BYD Atto 3
- Steering Configuration
- Left-Hand Drive & Right-Hand Drive
- Category
- Exterior Body Parts
Shipping & Returns
Ships worldwide from Shanghai, China via air or sea freight. Standard delivery 5–30 business days, express 2–10 business days. Shipping cost is calculated at checkout.
7-day return window for unused items in original packaging. Contact us before returning any item.
AC/DC charging port cover assembly I Workshop Guide — BYD Atto 3
AC/DC Charging Port Cover Assembly - Removal and Installation
Removal
- Remove the right front wheel mudguard assembly. See Right Front Wheel Mudguard Assembly - Removal and Installation
- Remove the charging port light. See Charging Port Light - Removal and Installation
- Disconnect 1 harness connector of AC/DC charging port cover assembly I.
- Detach the cover cable from the integrated AC/DC charging socket.
- Pry up the AC/DC charging port cover assembly I.
Install
- The installation is performed in reverse order of removal.
Charging Port Light - Removal and Installation
Removal
- Power off the low voltage electrical system. See Power-off and Power-on of Low Voltage Electrical System
- Remove the front compartment right trim panel assembly. See Front Compartment Right Trim Panel Assembly - Removal and Installation
- Disconnect 1 connector of the charging port light.
- Pry up the charging port light.
Installation
- The installation steps are opposite to the removal steps.
AC/DC charging port cover assembly I Fitment Diagram — BYD Atto 3
