OEMAftermarket
BYD Atto 3
Rear center mounting bracket for fender
OE / Material Codes
13623557-00SC2E-5401157Q/77$22USD
In StockNeed bulk or wholesale pricing?
Technical Specifications
- Vehicle Model
- BYD Atto 3
- Steering Configuration
- Universal (Left & Right-Hand Drive)
- Category
- Fenders & Mudguards
Shipping & Returns
Ships worldwide from Shanghai, China via air or sea freight. Standard delivery 5–30 business days, express 2–10 business days. Shipping cost is calculated at checkout.
7-day return window for unused items in original packaging. Contact us before returning any item.
Compatible Vehicles — Rear center mounting bracket for fender
BYDYuan PLUS/Atto 3
2022–2025Rear center mounting bracket for fender Workshop Guide — BYD Atto 3
Console Rear Mounting Bracket Assembly - Removal and Installation
Removal
- Remove the console body assembly. See Console Body Assembly - Removal and Installation
- Remove the interior detection antenna assembly (console rear mounting bracket). See Interior Detection Antenna Assembly (Rear Mounting Bracket of Console) - Removal and Installation
- Detach the floor wiring harness clip from the console rear mounting bracket assembly.
- Detach the instrument wiring harness clip from the console rear mounting bracket assembly.
- Remove 2 clips connecting the console rear mounting bracket assembly and the carpet.
- Remove the console rear mounting bracket assembly.
- Remove 2 fixing nuts.
- Remove 2 fixing screws, and take out the console rear mounting bracket assembly.
Installation
- The installation steps are opposite to the removal steps.
Left Rear Fender Bracket - Removal and Installation
Removal
- Remove the left front wheel mudguard assembly. See Left Front Wheel Mudguard Assembly - Removal and Installation
- Remove the front compartment left trim panel assembly. See Front Compartment Left Trim Panel Assembly - Removal and Installation
- Remove 2 fixing bolts from the left rear fender bracket.
- Remove 3 fixing bolts, and take out the left rear fender bracket.
Installation
- The installation steps are opposite to the removal steps.
Right Rear Fender Bracket - Removal and Installation
Removal
- Remove the right front wheel mudguard assembly. See Right Front Wheel Mudguard Assembly - Removal and Installation
- Remove the front compartment right trim panel assembly. See Front Compartment Right Trim Panel Assembly - Removal and Installation
- Remove the upper fasteners from the right rear fender bracket.
- Detach 1 wiring harness clips.
- Remove 2 fixing bolts, and take out the right rear fender bracket.
- Remove 3 fixing bolts, and take out the right rear fender bracket.
Installation
- The installation steps are opposite to the removal steps.
Rear center mounting bracket for fender Fitment Diagram — BYD Atto 3
